Overall dimensions:

Length : 1010 mm. Width : 450mm. Height : 975mm.

Gross weight : 53.0 Kg approx.
Load bearing capacity : 350 Kg UDL
Holder accommodated :
BT-30 = 20 Nos.
BT-40 = 18 Nos.
BT-50 = 10 Nos.
(HSK A-50,HSKA-63,HSK A-100 also available)

Colour :
Tool Trolley available in Dual colour Black Matt &VIP Blue structure.
(Also provide in other colour as per requirement.)

Product Code :- BST-3

Structure of Trolley :

Prime quality CRCA sheet and MS COIL section used.

All sheet metal cutting work done by Precise laser cutting and Bending process by 5 axis CNC Press Brake.

Finish : Dual colour Epoxy powder coating with Seven tank processed Phosphating treatment.

Features :-

  • 2 Nos. of 524mm(L) X 420 mm(W) X 100mm(H) drawers with 45 Kg Capacity for Day/Night Operator locker.
  • One 620mm(L) X 450mm(W) X 445mm(H) cupboard storage for Tools, Gauges and Instrument storage with lock.
  • 450mm X 200mm front tray with rubber foam for placing tools.
  • Wheel: Heavy duty 125 mm X 32 mm PU castors 2 Nos. Swivel & 2 Nos. Swivel with Brake.
  • Holder Cup : High quality Nylon cup used for longer life with life time service support.
  • Drawer : Heavy duty 45 Kg telescopic runner of Hettich brand used.
  • Each having Individual Lock.
